La configuración de los televisores de la serie UJ7700, tal modelo está representado en el mercado de América del Norte, la televisión tiene un panel IPS, soporte HDR, que se ha convertido en tradicional en los últimos dos años, aunque el vídeo se toma con soporte HDR es muy pequeño.
Los ajustes ayudarán a mejorar la imagen mostrada por el televisor.
SETTINGS |
WHITE BALANCE | ||||
| Picture Mode | Expert (Dark Room) | IRE | Red | Green | Blue |
| Aspect Ratio | Original | 5 | -6 | -3 | -14 |
| Energy Saving | Off | 10 | -3 | -3 | -10 |
| Picture Mode Settings | 15 | -2 | -1 | 0 | |
| Backlight | 39 | 20 | -9 | -9 | 3 |
| Contrast | 90 | 25 | -7 | -8 | 2 |
| Brightness | 50 | 30 | -0 | -2 | 5 |
| H Sharpness | 0 | 35 | -3 | -6 | 0 |
| V Sharpness | 0 | 40 | -2 | -4 | -2 |
| Color | 51 | 45 | -1 | -3 | -3 |
| Tint | 0 | 50 | -1 | -1 | 0 |
| Picture Options | 55 | 0 | -2 | 1 | |
| Noise Reduction | Off | 60 | -8 | -5 | -2 |
| MPEG Noise Reduction | Off | 65 | -9 | -4 | -1 |
| Black Level | Low | 70 | -3 | -1 | 5 |
| LED Local Dimming | Off | 75 | -4 | 3 | 7 |
| TruMotion | Off | 80 | -2 | 0 | 9 |
| Expert Control | 85 | -3 | -1 | 12 | |
| Dynamic Contrast | Off | 90 | -8 | -6 | 12 |
| Super Resolution | Off | 95 | 0 | -3 | 19 |
| Color Gamut | normal | 100 | 0 | 0 | 35 |
| Edge Enhancer | Off | ||||
| Color Filter | Off | ||||
| Gamma | 2.2 | ||||
| White Balance | |||||
| Color Temperature | Warm2 | ||||
| Method | 2 point | ||||
| Pattern | Outer | ||||
| Point | Low |
